業務で使える簡単なSSR + SPA のテンプレートを公開した
目次
久しぶりのブログです。
よく Node.js の人と思われがちですが、普段は Node.js でのバックエンド開発はもちろんですが React や Vue を書いていますので、たまにはフロントエンドネタを投稿しようと思います。
GitHub - hiroppy/ssr-sample: A minimum sample of Server-Side-Rendering, Single-Page-Application and Progressive Web App
A minimum sample of Server-Side-Rendering, Single-Page-Application and Progressive Web App - hiroppy/ssr-sample
リポジトリにあるコード見たほうが早いと思いますので、ここでは注意点等を列挙していこうかなと思います。
主な技術スタック
dependencies
- react@16
- react-router-dom@4
- react-helmet@5
- react-loadable@5
- redux@4
- [email protected]
- styled-components@3
- express@4
- dotenv@6
devDependencies
- typescript@3
- [email protected]
- jest@23
- ts-node@
- webpack@4
- workbox@3
注意
今回は、自分の好き嫌いも含め以下のことを導入しませんでした。
- Atomic Design
- こんな簡単なコードに 5 層もいらない
- decorators
@connect
を普段使わないのとまだ実験中なため
bindActionCreators
- 途中でカスタマイズが必要になってはじめ使ってて対応できなくなって結局消すため(経験談)
- サンプルコードなので、最低限必要なものしかいれない
Server
Server Side Rendering を行う
一番キモになる部分です。 その中では、SPA 時と同様に動かすためフロントエンドのコードを使って実行します。
// [server] renderer.ts
const store = configureStore();const sheet = new ServerStyleSheet(); // styled-components用const jsx = ( <Provider store={store}> <StaticRouter location={req.url} context={{}}> <div id="root"> <Router /> </div> </StaticRouter> </Provider>);
// sagaの処理が停止するとここが解決されるstore .runSaga(rootSaga) .done.then(() => { const preloadedState = JSON.stringify(store.getState()); const helmetContent = Helmet.renderStatic(); const meta = ` // helmetからheadに入れる情報を取得する ${helmetContent.title.toString()} ${helmetContent.meta.toString()} `.trim(); const style = sheet.getStyleTags(); const body = renderToString(jsx); // sagaにより更新されたstoreを使い再度レンダリングする
res.send(renderFullPage({ meta, assets, body, style, preloadedState })); // html生成 }) .catch((e: Error) => { res.status(500).send(e.message); });
// redux-sagaの起動及び非同期処理とstyled-componentsがstyleを抜く作業をさせるrenderToStaticMarkup(sheet.collectStyles(jsx));
// forkで動いているredux-sagaを止める(そうしないとずっと起動していてレスポンスが返せない)store.close();
https://github.com/hiroppy/ssr-sample/blob/master/src/server/controllers/renderer/renderer.tsx
// [client] configureStore.ts
const sagaMiddleware = createSagaMiddleware();
export const configureStore = (preloadedState: Object = {}) => { const enhancer = createEnhancer(); const store: Store & { runSaga: SagaMiddleware<typeof rootSaga>['run']; // 型を追加 close: () => void; } = createStore(rootReducer, preloadedState, enhancer);
sagaMiddleware.run(rootSaga);
store.runSaga = sagaMiddleware.run; // renderer.tsで呼べるように追加 store.close = () => { // renderer.tsからsagaを止める命令を送るメソッドを追加 store.dispatch(END); // forkされているsagaを止めてrenderer.tsのstore.runSaga(rootSaga).doneを解決させる };
https://github.com/hiroppy/ssr-sample/blob/master/src/client/store/configureStore.ts
SSR 時には<html>
, <head>
を含む HTML を生成しないといけないため文字列として手動で生成する必要があります。
また、react-helmet は SSR 時には生成されないため、手動でmeta
などを抽出する必要があります。
それ以外は、クライアント側のコードを利用します。
html 生成コード は こちら 。 以下がクライアント同様に行うこととなります。
redux-saga を使って非同期処理
-
render 系のメソッドを使って、redux-saga を起動させます。 あくまでも目的がキックであり差分更新に関する処理が必要ないため、
renderToString
より軽量なrenderToStaticMarkup
を使います。 -
処理が終わり次第、redux-saga へ止める命令を送ります。(
store.close()
を経由し、END
アクションを発行) -
store.runSaga(rootSaga).done
が解決されるため、その中で更新された store のデータを抽出しクライアントに初期の state をわたすように<script>
タグに埋め込みます。 -
store が更新されたため、再度レンダリング(
renderToString
)を行い、store の結果を反映させた HTML を生成します。 一回目のレンダリングではもちろん store の値は空なのでその戻り値の HTML にはデータは存在しません。
つまり、キック用と HTML 生成用のレンダリングが最低 2 回は必要ということです。
react-helmet を使って head タグを生成
クライアントで行うときと異なって、サーバーでは head タグに対して動的差し込みができないためレンダリングをし、手動で html に差し込む必要があります。
なので、redux-saga の一回目のレンダリングに便乗して、react-helmet の要素を抽出します。
redux-saga の解決後、そこで必要なタグを取得(helmetContent.title.toString()
)し HTML の生成関数へ流します。
styled-components で使われている css を抽出
redux-saga の一回目のレンダリングに便乗して、styled-components で書かれたコンポーネントの css を抽出します。
クライアントが HTML を受け取った時にレンダリングされた DOM の css がないと見た目が一致しないためです。
そこで抽出したstyle
タグを HTML の生成関数へ流しhead
へ挿入します。
Development
Hot Module Replacement を有効にする
開発時には HMR を有効化するために、webpack のビルドを Node サーバー起動時に行います。(また、フロントエンドではhydrate
ではなく、render
にします ※後述)
if (process.env.NODE_ENV !== "production") { const webpack = require("webpack"); const webpackHotMiddleware = require("webpack-hot-middleware"); const webpackDevMiddleware = require("webpack-dev-middleware"); const config = require("../../webpack.config"); const compiler = webpack(config);
app.use(webpackHotMiddleware(compiler)); app.use( webpackDevMiddleware(compiler, { publicPath: config.output.publicPath, }), );}
https://github.com/hiroppy/ssr-sample/blob/master/src/server/server.ts#L15-L28
Production
今回は、webpack をかけずに ts-node で開発も本番も起動させます。
Manifest を読み込む
本番環境では、ファイル名にハッシュを含めるためコアコードは manifest ファイルを参照しクライアントに返す<script>
を生成していきます。
今の自分のコードでは、起動時に読み込むようにしていますが、サーバーを再起動させたくなければリクエストが来た時に fs を使って manifest を読み込むように変えればいいです。
基本、サーバーのコードもクライアントのコードべったりなので起動時になると思いますが。。
const assets = ( process.env.NODE_ENV === "production" ? (() => { const manifest = require("../../../dist/manifest"); return [manifest["vendor.js"], manifest["main.js"]]; })() : ["/public/main.bundle.js"]) .map((f) => `<script src="${f}"></script>`) .join("\n");
Cluster を使う
負荷分散のために Cluster を行います。
const numCPUs = cpus().length;
if (cluster.isMaster) { [...new Array(numCPUs)].forEach(() => cluster.fork());
// もし落ちたら再起動をかける cluster.on("exit", (worker, code, signal) => { console.log(`Restarting ${worker.process.pid}. ${code || signal}`); cluster.fork(); });} else { runServer();}
https://github.com/hiroppy/ssr-sample/blob/master/src/server/index.ts#L13-L25
Benckmark
SSR するサーバーのパフォーマンスチューニングを必要とする場面はあると思います。 autocannon を使い、server 側のベンチマークを取ります。 これで React から静的な HTML を生成し返すまでの Latency を計測します。
GitHub - mcollina/autocannon: fast HTTP/1.1 benchmarking tool written in Node.js
fast HTTP/1.1 benchmarking tool written in Node.js - mcollina/autocannon
> autocannon http://localhost:3000 -c100Running 10s test @ http://localhost:3000100 connections
Stat Avg Stdev MaxLatency (ms) 153.89 138.41 2479.02Req/Sec 643.5 86.29 758Bytes/Sec 1.64 MB 214 kB 1.94 MB
6k requests in 10s, 16.5 MB read
もっと詳細に知りたい場合はperf_hooks
を使い、renderToString
の実行時間を測ることが可能です。
可視化する
clinic を使い詳細な情報を可視化して確認することが可能です。
GitHub - clinicjs/node-clinic: Clinic.js diagnoses your Node.js performance issues
Clinic.js diagnoses your Node.js performance issues - clinicjs/node-clinic
イベントループの情報や flame の情報を表示でき、かなりわかりやすく便利なのでオススメです。
https://github.com/hiroppy/ssr-sample/blob/master/package.json#L14-L16
renderToNodeStream をなぜ使わないか?
gist に貼られた以下のコードはrenderToNodeSteam
で書いたコードです。
https://gist.github.com/hiroppy/1c89d73a12073bad0c187aaab4ca92c2
互いに文字列を挟んで書くのが個人的に好きじゃないのと、react-helmet がまだ steam に対応していない(PR: nfl/react-helmet#296 )のが主な理由です。
res.write("<html><head><title>Test</title></head><body>");const stream = sheet.interleaveWithNodeStream(renderToNodeStream(jsx));stream.pipe(res, { end: false });stream.on("end", () => res.end("</body></html>"));
自分的には、パフォーマンスがやばくなってきたら考える程度の温度感です。
Client
UI 構成
PWA と同様に、App Shell と Content に分けています。
PWAの実装をしてみた - hiroppy's site
Node.jsでのパフォーマンス改善の方法のtipsをまとめます

次のページに行った時に前のページと同じ App Shell の場合は Content だけをレンダリングします。(connect
してある場合はその箇所だけレンダリングします)
今回は、header が App Shell であり、Content は react-router で選ばれた dynamic import されているコンポーネントです。
export const Main = ({ children }: Props) => ( <React.Fragment> <Header /> <Container>{children}</Container> {/* このchildrenはreact-routerから来たcontent*/} </React.Fragment>);
https://github.com/hiroppy/ssr-sample/blob/master/src/client/components/templates/Main/Main.tsx
// App がheader等を持っているexport const Router = () => ( <App> <Switch> <Route exact path="/" component={LoadableTop} /> <Route path="/orgs/:org" component={LoadableOrgs} /> </Switch> </App>);
https://github.com/hiroppy/ssr-sample/blob/master/src/client/Router/Router.tsx
Meta
meta タグの決定は、Atomic Design でいうpages
で行います。
これは SSR 時にも使われるため共通化された処理です。
export const Top = () => ( <React.Fragment> <Head title="top" /> <h1>Top</h1> </React.Fragment>);
https://github.com/hiroppy/ssr-sample/blob/master/src/client/components/pages/Top/Top.tsx
render vs hydrate
開発時には、フロントエンドのコード変更が多くサーバから作られた HTML と一致しない場面が多くなるため、hydrate
は使いません。
本番では、hydrate
を使います。
const renderMethod = module.hot ? ReactDOM.render : ReactDOM.hydrate;
https://github.com/hiroppy/ssr-sample/blob/master/src/client/index.tsx#L14
redux-saga のテスト
自分の場合は redux-saga-test-plan を使いテストのシナリオを作ります。 また、コード置換として proxyquire 、 rewire 、HTTP サーバーの mock として nock を使います。
GitHub - jfairbank/redux-saga-test-plan: Test Redux Saga with an easy plan.
Test Redux Saga with an easy plan. Contribute to jfairbank/redux-saga-test-plan development by creating an account on GitHub.
Page Not Found
例えば、今回のような API を叩くテストは以下のように書きます。
const initialState = { name: "name", repos: [],};
test("should take on the FETCH_REPOS action", () => { nock("https://api.github.com") // https://api.github.com/orgs/test/repos の返す値を設定する .get("/orgs/test/repos") .reply(200, [ { forks_count: 100, name: "foo", html_url: "url", language: "lang", open_issues_count: 200, stargazers_count: 300, watchers_count: 400, }, ]);
return expectSaga(orgsProcess) .withState(initialState) .put({ type: "FETCH_REPOS_SUCCESS", payload: { name: "test", repos: [ { forksCount: 100, name: "foo", url: "url", language: "lang", issuesCount: 200, stargazersCount: 300, watchersCount: 400, }, ], }, }) .dispatch({ type: "FETCH_REPOS", payload: { org: "test", }, }) .run();});
https://github.com/hiroppy/ssr-sample/blob/master/src/client/sagas/orgs.test.ts
Misc
Dotenv
docker-compose で起動する時や本番デプロイ時には、.env
を使って環境変数を入れることが多いとも思います。
今回のサンプルでは、クライアント側では dotenv-webpack 、サーバー側では webpack を通さないため dotenv を使い共通の.env
を読み込みます。
https://github.com/hiroppy/ssr-sample/blob/master/webpack.config.js#L36-L39
Dynamic Import
tsconfig
client と server の tsconfig を分ける必要があります。
"module": "commonjs",
と指定した場合、
Promise.resolve().then(function () { return require("./foo");});
と置換してしまい、webpack でチャンクとして切れないためです。
webpack 側に dynamic import ということを知らせるため、esnext
を指定し、変換をさせないようにする必要があります。
しかし、esnext
と書くと無変換になるため Node.js では ESM のシンタックスが存在しないため、サーバー側がエラーとなります。(つまりcommonjs
でないとダメ)
故に、以下のように分ける必要があります。
// server{ "extends": "tsconfig.base.json", "compilerOptions": { "module": "commonjs", "moduleResolution": "node" }}
// client{ "extends": "tsconfig.base.json", "compilerOptions": { "module": "esnext", "moduleResolution": "node" }}
今 Node.js では ESM が実験中で動きますが、それが本番に入ればっていう話でもなく、なぜかというと Node.js において ESM は拡張子が.mjs
であるからです。
なので、ts 側が吐くファイルの拡張子を.mjs
にしないといけなく、一筋縄ではいかないように思えます。
結論としては、TypeScript 使ってて webpack で dynamic import されたファイルをチャンクとして切りたい場合は、module: esnext
にしましょう!
react-lodable
活発ではなく、今から選ぶのはあまり良くないと思います。 また、issue がないのが情報量少なく、個人的にはつらいです。
問題点
webpack4 に対応していない
Migrate to webpack@4 API by 7rulnik · Pull Request #110 · jamiebuilds/react-loadable
なぜか webpack4 の PR の会話が span としてロックされた
結構致命的だと思いますが、webpack4 だと SSR 時にLoadable.Capture
から dynamic import で使われるスクリプト名を取得できないです。
Lodable.Capute
を実行しなくても HTML 的には dynamic import も展開してくれるので SEO 等には問題ありません。
HTML に script タグを埋め込まない場合、すでに読み込み済みの HTML に対して、client 側は認知していなく、dynamic import されるファイルをサーバーへ取得しにいくため、すでに表示されているのにローディングに UI を切り替えてしまうのが問題となります。
componentWillMount
等を使っているため警告がでる
警告が出ます。
型定義がおかしい
render
は optional なのに、現在は必須です。
本来、OptionsWithoutRender
に行くべきなのにOptionsWithRender
が優先されるのが問題です。(PR を出す必要あり)
なので現在は、以下のように再定義を行っています。
export const LoadableOrgs = Loadable({ loader: () => import(/* webpackChunkName: "Orgs" */ '../containers/Orgs').then(({ Orgs }) => Orgs), loading: () => <div>loading ...</div>} as Loadable.OptionsWithoutRender<unknown>);
https://github.com/hiroppy/ssr-sample/blob/master/src/client/Router/Routes.tsx
loadable-components
GitHub - gregberge/loadable-components: The recommended Code Splitting library for React ✂️✨
The recommended Code Splitting library for React ✂️✨ - gregberge/loadable-components
API がシンプルで、すごいわかりやすく好きです。
ただ、babel プラグインに依存しており、loadable-components/babel
を使わないと SSR は実行できないため必須です。
そこだけどうにかしてほしい。。
さいごに
まだ、dynamic import 周りが自分の中で何をデファクトにするか悩んでいます。(といっても、このままいくと自然と loadable-components しかない)
